GEMLink, has been upgraded with a variety of new features to enable easier visualization of results and deliver basic forward modeling.
This version of GEMLink is intended to be more stable and high capacity for serial port data transfer for all Windows OS with several improvement and bug fixs. The software is available for free download from the web site.
You can keep original GemLink V5.2, v 4.0 and V3.0 in the same PC.
If you experience any difficulties or have suggestions, we would appreciate hearing your comments. Please send an email to email@example.com and include “GEMLink V5.3” in the header line of your email.
Welcome to the v5.2 version of GEMLink for Windows. This version of GEMLink is intended to provide an reliable and robust system for rugged applications for all Windows OS. It allows Multiple GemLink running simultaneously without confliction. Also it gives an upgraded interface to the Windows operating system and streamline data transfer to and from the magnetometer. The software is available for free download from the web site.
You can keep original GemLink V4.0 and V3.0 in the same PC.
If you experience any difficulties or have suggestions, we would appreciate hearing your comments. Please send an email to firstname.lastname@example.org and include “GEMLink V5.2” in the header line of your email.
The serial components of serial communication has been completely migrated from VB v6.0 to .net. It allows most of USB-RS232 driver working seamlessly. It will overcome most problems when running on Windows Vista/7.
Processor: minimum 800MHz
RAM: minimum 500 MB
Hard: Disk Space minimum 500 MB
OS: Windows 2000, Windows XP, Windows Vista, Windows 7
The new Windows version of GEMLink migrated from VB v6.0 to VB.net. It gives robust data transfer with software flow control. Also it added some new features including real-time data plotting, magnetic field map plotting, mirror data plotting.
The software is available for free download from the web site. It offers a number of time-saving features including Personal Computer-based data reduction, Internet software upgrades, way point transfer and merging of magnetometer and DGPS data.
* Real-time Data Plotting
* Basic magnetic map plotting feature
* Stack Data Plotting
* Hex code capture
As shown below, users can capture real-time sampling on main window while plotting on other windows simultaneously. User can select the columns to monitor magnetic fields simultaneously up to four channels. By changing the Min/Max values manually, the plot can be zoomed in/out. It is very useful to set up, tune system.
It can show up to 10 minutes historic data.
Figure 1.1. Real-time Data Plotting.
A basic magnetic map plotting feature is added as shown below.
For some application such as VLF, it may need to plot stacked or mirror pictures to tune or adjust sensors & systems. In version 5.0, two applications are added as shown below.
In version 5.0 User can either capture ASCII code or Hex code.
To download the latest version, click here.
We would appreciate hearing any feedback you may have so that we can make improvements / additions in future. To send a short email, click here.BACK
If you would like to receive a callback from GEM Systems.
